50HP and 60HP Dryland crawler tractor

Product No.：2025331151356
Online Inquiry

Product description:

The frame is reasonably designed and uses thickened steel plates. It is strong and durable, reducing vibration generated by the engine and extending the life of the machine. The lengthened chassis makes the grounding area of the cover belt longer and wider, which also ensures the stability of the front and rear of the machine, making climbing, crossing ditches and other complex terrain safer and smoother. The engine adopts 4-cylinder Laidong, Changchai, and other engines. The gearbox adopts the gearbox specially developed for belt-covered tractors independently developed by the factory. It has strong power and flexible response. It has 4 forward gears, 1 reverse gear, high and low speed gears, and the rear power output has high and low speed gears. The machine's steering uses mechanical power cut-off to extend its service life. The rear-mounted suspension (with suspension) is compatible with all wheeled tractors and agricultural machinery.

This vehicle is equipped with a hydraulic oil radiator. Reduce transmission oil temperature during use. Avoid damage to the gearbox. and control failure. Install a water tank radiator. Increase water tank capacity. It can effectively reduce the high temperature generated by the engine during use. The air filter is a dry filter that can filter a large amount of dust and soil.

One driving wheel and 6 supporting wheels are installed on one side. Design of 2 top wheels and 1 tension wheel. Use 7 rollers. It can effectively distribute the weight of the machine to each wheel, thereby reducing the load-bearing weight of the wheel. Make the wheels more durable.

The use of two top wheels can reduce the trembling amplitude of the covering belt and prevent the track from derailing.

The sheet metal parts of the machine are all made of thickened steel plates above T4. Strong and durable, not easy to deform. The paint color is automotive metallic flash paint. Strong adhesion and weather resistance.

The diesel tank has large capacity and long battery life.

Use high-quality two-way distributor, long life and fast response.

Product :

Product parameters:

Model: DTD-50/60	Walking speed: 20km/h
Overall dimensions :(length × width × height) 2700 × 1350 × 1300mm	Working speed: about 3-5 acres/hour
Diesel engine brand: Weinei/Laidong engine	air filter : paper oil filter
Overall machine weight: 1300/1600kg	Water tank: In cold weather, the antifreeze water tank needs to be replaced and there must be no shortage of water.
Fuel consumption : 2-3 liters/acres	Gears: 4 forward gears, 1 reverse gear, a total of 10gears for high and low speeds
Transmission mode: Shaft drive	Gearbox: Patented machinery, the gearbox is simple to operate and has a low failure rate
Track size: width 230×72×54mm	Engine speed : 2400rpm
Optional rotary tillage, weeding, trenching, backfilling, dozer blade, ridging, seeding, double plow, loading shovel, bucket functions, etc.
Can be used with all wheeled tractors and agricultural implements with suspension

FAQ:

1.Q:Are you manufacturer or trade company?

A: We are manufacturer, we have our own factory. Our factory has department for exploitation , producing, sales, after-sell service, packing , warehouse, we can offer you best products and best service.

2.Are you interested in dealership with local company?

A: Yes, we are quite interested in this business cooperation. We'd like to cooperate with some local partner to sell more machines in local market and supply better service.We can discuss more if you also interested.

3. Q: Do you sell accessories for your machine?

A: Yes, all of matching accessories for our machine are on selling, we are willing to supply the matching parts to you with low price.

4.Q: What's your terms of packing?

A: Generally, we pack our goods in wooden cases.

5.Q: What's your terms of payment?

A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

6.Q: What's your terms of delivery?

A: EXW, FOB, CFR, CIF

7.Q: How about delivery time?

A: Generally, it will take 7 to 20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

8. Q: How do you make our business long-term and good relationship?

A: 1. We keep good quality and competitive price to ensure our customers benefit;

2. We respect every customer as our friend, no matter where they come from;

3. If you have any feedback that is cherished to us, please send email to us.

9.Q: Do you supply samples?

A: We support sample order .

10.Others: OEM: Support technical changes.

Free train: plant training on installation and maintenance techniques.

QC: Quality inspection before delivery for each unit.
